The TENKILOMETERS high quality ZXHN F663NV3a SINGLE BAND WIFI XPON ONU ONT FTTH is a single-frequency and economical smart gateway specially built by ZTE for China Mobile. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem.
|
Technical items |
Descriptions |
|
Model |
ZXHN F663NV3a |
|
Fiber interface |
SC/UPC |
|
Fiber port |
1 XPON interface, 1GE+3FE+1POT+1USB+WIFI,SC single-mode, |
|
Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
|
|
Wavelength |
Tx 1310nm, Rx 1490nm |
|
Voice protocol |
SIP, H.248 |
|
RX sensitivity |
<-27dBm (1490nm) |
|
WLAN |
IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna |
|
Net weight |
≤0.6Kg |
|
Configuration method |
NMS, Web, or TR069 |
|
Power |
≤8W |
|
DC power |
Adapter input: 100-240 V AC, 50 – 60 Hz ; |
|
Adapter output: 11 – 14 V DC, 1 A |
|
|
Button |
Reset, power |
|
Operation |
Working temperature: -0-+40℃ |
|
working humidity:5-95%(non-condensation) |
|
|
Dimension |
250*220*65mm(length*width*height) |
|
L2 forwarding capability |
Forwarding packets of any length at wire speed |
|
IPv4 L3 forwarding capability |
2Gbit/s with any length packets in downstream direction |
|
1Gbit/s with any length packets in upstream direction |
|
|
IPv6 L3 forwarding capability |
2Gbit/s with any length packets in downstream direction |
|
1Gbit/s with any length packets in upstream direction |
|
|
LAN |
1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
· highly reliable heat dissipation design guarantees its stable operation.
· dual image ensures uninterrupted services during software downloading or upgrading, thereby enhancing software reliability
· highly reliable lightning protection design provides lightning and surge protection of 4 kV for the adapter, 1.5 kV for the Phone interfaces, and 1.5 kV for the Ethernet ports.
· full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation, administration and maintenance (OMCI/TR-069) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator’s network.
