TENKILOMETERS has quality F663N Single Band GPON ONU ONT. It is an optical network terminal (ONT), high-end home gateway in FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. At the same time, F663N features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Based on them, F663N provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
|
Model |
F663N |
|
Fiber Type |
GPON ONU |
|
Support |
IEEE802.1Q Virtual LAN |
|
Technical item |
1GE+3FE+1POTS+USB+WIFI |
|
dimension |
28*20*8cm |
|
Firmware/Interface |
English |
|
Power adapter |
UK, US, EU, AU etc |
|
Use |
FTTH |
|
System power supply |
12 V DC, 1 A |
|
Dimensions (length x width x height) |
165mm x 28 mm x 110 mm |
|
Working environment |
Operating temperature: -5ºC to 45ºC |
· GPON ONT, 1*GE, 3*FE, 1*POTS With WiFi, 1*USB 2.0
· Connector type SC/UPC
· ENG firmware
· WiFi Standard: IEEE 802.11b、 IEEE 802.11g、 IEEE 802.11n
· Can be configured by OLT or Web or NMS
· Packing dimension : 165*28*110mm
· Routing function supported
· GPON ONT F663N provides three FE Ethernet ports, one GE Ethernet port, one POTS port and one USB. F663N has WiFi function, support 802.11 b/g/n.
