Model No. |
Enternet Ports |
Voice |
Router (PPPoE) |
Wifi |
Firmware Language |
|
ZXHNF609 V3 |
1GE+3FE |
1pots |
Yes |
Yes |
English |
The TENKILOMETERS high quality F609 V3 is a XPON Optical Network Terminal designed for HGU (Home Gateway Unit) used in FTTH scenario, which supports L3 function to help subscriber construct intelligent home network.ZTE F660 provides an XPON interface to connect OLT with an ODN. It offers a new choice for operators to deliver FTTH access.
POL (Passive Optical LAN) is a new type of LAN networking solution based on PON technology, which combines different services such as data, voice, video, and wireless access into one optical fiber network, inheriting the PON network With the advantages of large bandwidth, high reliability, low latency, flatness, easy deployment, and easy management, it is the best choice for different scenarios such as smart parks, commercial buildings, enterprises, campuses, hotels, governments, and finance.
|
Model |
F660V8.0 |
|
Optical port |
1 x XPON interface |
|
Transmission Distance |
0-20KM |
|
Transmit rate |
2.488Gbps downstream; 1.244Gbps upstream |
|
User-Network Interface |
1GE +3FE port |
|
1 x Wi-Fi interface |
|
|
1 x USB host interface |
|
|
1 x POTS interfaces |
|
|
Wavelength |
Receiving: 1480~1500 nm Transmitting: 1290~1330 nm |
|
Receiving Sensitivity |
-28dBm |
|
Transmitting Optical Power |
0.5~5dBm |
|
Power consumption |
<10W |
|
Dimensions |
220mm(W) x 44mm(H) x 160mm(D) |
|
Working temperature: |
0oC ~ 40oC |
|
Working humidity |
5% ~ 95% |
|
Weight |
380G |
|
Power supply |
12V DC |
